This slim chartplotter boasts the brightest, sharpest, most colorful graphics you’ve ever seen on a 5-inch screen. The GPSMAP 525 has a 5” VGA display; built-in, worldwide satellite-enhanced basemap; and simple, straightforward buttons and menus. You can add the optional BlueChart® g2 Vision SD™ card for even more enhanced features.

Navigate with Ease
The 525’s worldwide basemap includes realistic satellite imagery that shows up clearly on its crisp, ultra-bright screen. The SD card slot makes it easy to add additional maps without connecting to a computer. And with a simple, intuitive interface and high-speed processor, the 525 makes navigating easy.

Add Extras with BlueChart g2 Vision
With the optional BlueChart g2 Vision SD card, you can add a whole new dimension of exceptional features to your chartplotter.

• 3D mariner’s eye view or fish eye view provides you with a 3-dimensional perspective of map information, both above the waterline and below it.
• High-resolution satellite images and aerial photographs help you orient yourself in unfamiliar areas.
• Auto Guidance technology searches through all relevant charts to create a route you can actually follow — one that avoids obstacles, shallow water, buoys and other obstructions.

For a low cost option try BlueChart g2® cards.

Physical & Performance:
Unit dimensions, WxHxD:  5.9" x 6.4" x 2.9" (15.0 x 16.3 x 7.4 cm)
Display size, WxH:  3.0" x 4.0", 5.0" diagonal (7.6 x 10.2 cm, 12.7 cm diagonal)
Display resolution, WxH:  480 x 640 pixels
Display type:  VGA display
Weight:  less than 1.75 lb (0.8 kg)
Battery:  none
Battery life:  none
Waterproof:  yes (IPX7)
High-sensitivity receiver:  no
Antenna:  internal
NMEA input/output:  NMEA 0183

Maps & Memory:
Basemap:  yes
Preloaded maps:  no
Ability to add maps:  yes
Built-in memory:  none (cannot load maps to internal memory)
Accepts data cards:  SD™ card slot
Waypoints/favorites/locations:  1,500
Routes:  20
Track log:  10,000 points; 20 saved tracks

Features:
Garmin radar compatible:  no
Garmin sonar compatible:  yes
CANet® compatible:  yes
Garmin Marine Network™ compatible:  no
Touchscreen:  no
Supports AIS (tracks target ships' position):  yes
Supports DSC (displays position data from DSC capable VHF radio):  yes
Audible alarms:  yes
Tide tables:  yes
Hunt/fish calendar:  no
Sun and moon information:  yes
3-D map view:  yes (with optional BlueChart g2 Vision card)
Auto Guidance:  yes (with optional BlueChart g2 Vision card)
Automatic routing (turn by turn routing on roads):  no
XM WX Weather & Radio for U.S. compatible:  no
Voice prompts (e.g. "Turn right in 500 ft."):  no
Speaks street names (e.g. "Turn right ON ELM STREET in 500 ft."):  no
Remote control:  no
Headphone jack/audio line-out:  no
Audio/video input/output:  no
Portable:  no
Automotive/motorcycle-friendly:  no
